PN-SAC3 Toggle Switch Datasheet
| Rating | 20A 12V DC |
| Contact Resistance | 50m ohm Max. |
| Insulation Resistance | DC 500V 100M ohm Min. |
| Dielectric Strength | AC 1500V 1 minute |
| Operation Temperature | -20℃ ~+85℃ |
| Switch Function | 3P SPST ON-OFF(LED Red) |
PN-SAC3 Starter Switch Datasheet
| Rating | 50A 12V DC |
| Contact Resistance | 50m ohm Max. |
| Insulation Resistance | DC 500V 100M ohm Min. |
| Dielectric Strength | AC 1500V 1 minute |
| Operation Temperature | -25℃ ~+85℃ |
| Switch Function | 3P SPST (ON)-OFF (LED Red) |
| LED Lens Color | ∅5 White diffuse |
| VF/IF | 3.7V/20mA |
| Frame | Nylon 66 (94V-2), Black |
| Cover | ABS(94HB) |
| Terminals | Copper Alloy |
| Actuator | PC (94V-2), Red |
