The Cnlinko YU-USB3-FS-MP-1M-001 is a USB 3.0 male plug with female socket and 1 meter of cable. Rated for 1.5A. Bayonet connection on socket. Designed to operate under harsh conditions. Used to send data inside the machine, as the socket can be mounted outside. Compatible with USB 2.0. Socket includes cap. Also known as YU-USB3-JSX-03-100
Specifications
- Type- Male Plug / Female Socket
- Cable Length- 1 Meter (3.28 Ft)
- Number of Contacts- 9
- Rated Current- 1.5 Amps
- Contact Resistance- <30 mOhm
- Withstanding Voltage- 100V
- Insulation Resistance- >500 MOhm
- Ingress Protection- IP 67 (when mated) – Indicates total protection from dust & temporary immersion in water (1 meter for 30 minutes)
- Durability- > 500 times
- Operating Temperature- -40 C to 80 C (-40 F to 176 F)
- Housing Material- High performance engineering plastic
- Hardware- Zinc Alloy
- Flammability Rating- UL94-V0
