Specifications
Dimensions- 62.5 mm Length x 29.2 mm Diameter (2.46″ x 1.15″)
Number of Pins- 9
Wire Gauge- 26-24 AWG
Diameter Range- 5.5-7mm
Contact Diameter- 1mm
Rated Current- 5 A
Operating Voltage- 400V
Contact Resistance- <5mOhm
Withstanding Voltage- 2500V
Insulation Resistance- > 500MOhm
Ingress Protection- IP65/67
Durability- > 500 times
Operating Temperature- -40 C to 80 C (-40 F to 176 F)
Housing Material- Zinc Alloy
Contact Material- Gold Plated Copper Alloy
Flammability Rating- UL94-V0
Approvals- CE, CCC, RoHS, ISO9001
Wiring Mode- Soldering
