- Gold plated contacts for greater corrosion protection
- Electromagnetic & radio frequency interference protection
- High temp & pressure resistant
- Rated IP65/67 when connected
- Comes with waterproof cap
Specifications
- Dimensions (without cap)- 28.7 mm Height x 31.4 mm Width (1.13″ x 1.24″)
- Number of Pins- 3
- Wire Gauge- 14-12 AWG
- Cable Diameter Range- 8-12 mm
- Contact Diameter- 2.7 mm
- Rated Current- 20A
- Operating Voltage- 500V
- Contact Resistance- <1mOhm
- Withstanding Voltage- 2500V
- Insulation Resistance- > 500MOhm
- Ingress Protection- IP65/67
- Operating Temperature- -40 C to 80 C (-40 F to 176 F)
- Lifespan- 1700 times
- Housing Material- Zinc Alloy
- Contact Material- Gold Plated Copper Alloy
- Wiring Type- Soldering
- Flammability Rating- UL94-V0
