| Brand: | CNLINKO |
| Series: | DH-Serie, DH-24-Power |
| Version (Plug / Chassis): | Cable Version |
| Connector type: | Power |
| Connection mode: | Quick bayonet lock |
| Number of contacts: | 3 |
| Contact diameter in mm: | 3 x Ø 3.00 mm |
| Gender (M / F): | Male plug |
| Connector housing color: | Alu – Red |
| Cable diameter min. in mm: | Ø 4 mm |
| Cable diameter max. in mm: | Ø 14 mm |
| Cable connection size min. in mm: | Ø 2.5 mm |
| Cable connection size max. in mm: | Ø 4 mm |
| Cable connection size min. in AWG: | AWG 14 |
| Cable connection size max. in AWG: | AWG 12 |
| Wiring mode: | Solder contact |
| Insulation component: | High performance plastics |
| Material connector housing: | Zinc alloy (nickel plated) |
| Material contact: | Copper alloy (gold plated) |
| Waterproof component: | Silicagel |
| Working temperature minimum: | -40° |
| Working temperature maximum: | +80° |
| Plug cycle: | ≥ 500 |
| Salt spray test: | PH 6.2 – 7.2, NaCI 1.5% 48h |
| IP protection class according to EN60529 2000: | IP67 |
| Classification flammability of plastics: | UL94-V0 |
| ROHS according to EN62321-1: | Yes |
کانکتور 3 پین تغذیه صنعتی قفل شونده ضد آب مدل DH24 ( ست کامل)
DH-24 power connector 3-pin 500 V 25 A IP67
3,570,000 تومان
17 در انبار
| Brand |
CNLINKO |
|---|
0
افرادی که هم اکنون این محصول را بازدید می کنند
General info
| Brand |
CNLINKO |
|---|
| Brand |
CNLINKO |
|---|---|
| type |
Power Connectors |
| Connector Size |
M24 |
| material |
Metal/Plastic |
